Dijkstra’s algorithm is one of the key algorithms we hear about within computer science. It can be slightly less accessible to beginners because you have to know what a weighted, directed graph is.
The algorithm takes a starting node and outputs minimum length paths to all other nodes.
I wanted to share my python code for this algorithm, because I think it’s a cool and useful one. Here a thorough explanation, and here is a great visualization.
You can view the code on mygithub as well!
# python 3 only!!! import collections import math class Graph: ''' graph class inspired by https://gist.github.com/econchick/4666413 ''' def __init__(self): self.vertices = set() # makes the default value for all vertices an empty list self.edges = collections.defaultdict(list) self.weights = {} def add_vertex(self, value): self.vertices.add(value) def add_edge(self, from_vertex, to_vertex, distance): if from_vertex == to_vertex: pass# no cycles allowed self.edges[from_vertex].append(to_vertex) self.weights[(from_vertex, to_vertex)] = distance def __str__(self): string = "Vertices: " + str(self.vertices) + "\n" string += "Edges: " + str(self.edges) + "\n" string += "Weights: " + str(self.weights) return string def dijkstra(graph, start): # initializations S = set() # delta represents the length shortest distance paths from start -> v, for v in delta. # We initialize it so that every vertex has a path of infinity (this line will break if you run python 2) delta = dict.fromkeys(list(graph.vertices), math.inf) previous = dict.fromkeys(list(graph.vertices), None) # then we set the path length of the start vertex to 0 delta[start] = 0 # while there exists a vertex v not in S while S != graph.vertices: # let v be the closest vertex that has not been visited...it will begin at 'start' v = min((set(delta.keys()) - S), key=delta.get) # for each neighbor of v not in S for neighborin set(graph.edges[v]) - S: new_path = delta[v] + graph.weights[v,neighbor] # is the new path from neighbor through if new_path < delta[neighbor]: # since it's optimal, update the shortest path for neighbor delta[neighbor] = new_path # set the previous vertex of neighbor to v previous[neighbor] = v S.add(v) return (delta, previous) def shortest_path(graph, start, end): '''Uses dijkstra function in order to output the shortest path from start to end ''' delta, previous = dijkstra(graph, start) path = [] vertex = end while vertexis not None: path.append(vertex) vertex = previous[vertex] path.reverse() return pathAnd an example, run on this graph:
# To run an example G = Graph() G.add_vertex('a') G.add_vertex('b') G.add_vertex('c') G.add_vertex('d') G.add_vertex('e') G.add_edge('a', 'b', 2) G.add_edge('a', 'c', 8) G.add_edge('a', 'd', 5) G.add_edge('b', 'c', 1) G.add_edge('c', 'e', 3) G.add_edge('d', 'e', 4) print(G) print(dijkstra(G, 'a')) print(shortest_path(G, 'a', 'e'))
